BCS-ZA1220 Power supply for a DIN rail

46,70 EUR including 23.00% VAT
Product code: #8053
Manufacturer: BCS
  • Switch-mode power supply
  • Mounting on a DIN rail
  • Output parametrs: DC 12V 2A max 30W
  • Output voltage signaling
  • Protection: SCP, OLP, OHP and overvoltage
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
BCS-MON7300B-S BCS IP video intercom monitor, black BCS-MON7200W-S video intercom monitor, white BCS-PAN1701S-S Single-family IP outdoor panel BCS-PAN1601S-S Single-family IP outdoor panel BCS-PAN1501G-S One-family IP outdoor panel BCS-PAN1300B-S One-family IP outdoor panel BCS-MON7400W-S Video intercom monitor, black-white BCS-MON7400B-S video intercom monitor, black BCS-MON7300W-S BCS IP video intercom monitor, white

BCS-ZA1220 Switching power supply for a DIN rail


12V DC switching power supply with adjustable output voltage in the range of 10.3-14V. It is designed to power external panels, video monitors, electric strikes and other 12V devices.
BCS-ZA1220 is characterized by high efficiency at the level of 90% and it has protection:
  • 12V output short circuit protection
  • anti-overload 3.5A level
  • thermal
  • overvoltage protection for DC outputs and AC inputs
Equipped there is an LED indicator that indicates the presence of the output voltage.
Mounting can be on a DIN rail or surface.

TECHNICAL DATA
  • input voltage range: 180 ÷ 240V AC 50 ÷ 60 Hz
  • output voltage: 10.3-14V
  • output current: max 2A
  • PSU power: 30W (continuous power)
  • efficiency (Typ.):> 85%
  • operating temperature range: -10 ° C ... + 40 ° C
  • housing dimensions: 70 × 90 × 65 mm
Download
CE Declaration 2.24 MB
