Roger PSD4D Supply and bus distributor module

72,61 EUR including 23.00% VAT
Product code: #22424
Manufacturer: Roger
  • Communication bus and power supply distribution to 4 doors
  • 4 supply outputs 12 V/1 A
  • 4 supply outputs 12 V/0.2 A
  • 0.3 A, 0.6 A or 0.9 A battery charging current
  • Supplied from 13.8 VDC/5 A power supply
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Roger MC16-EVC-64 Conventional Elevator Access Controller Roger MC16-LRC-64 Locker Access Controller Roger MC16-EVC-32 Conventional Elevator Access Controller Roger MC16-LRC-32 Locker Access Controller Roger MC16-EVC-16 Conventional Elevator Access Controller Roger MC16-LRC-16 Locker Access Controller Roger MC16-BAC-8 Building Automation Controller Roger MC16-HRC-4 Hotel Room Access Controller Roger MC16-BAC-64 Building Automation Controller Roger MC16-HRC-1 Hotel Room Access Controller

Roger PSD4D Supply and bus distributor module


PSD4D distributes power supply and RS485 bus to 4 doors. For each door it offers RS485 interface, 1.0A main power supply output and 0.2A auxiliary power supply. Short circuit at output and communication lines of particular door do not affect lines at remaining doors. The PSD4D is supplied from the 13.8VDC PSU which provides power for electronic module and door equipment, including door lock and readers. In case the external power supply is lost, the system is supplied from the backup battery connected to the PSD4D distributor and charged with 0.3A, 0.6A or 0.9A current. PSD4D is equipped with removable terminal blocks which facilitate electrical connections during installation and maintenance. The PSD4D distributor is mainly used in access control systems with MCT-IO readers which are equipped with on-board inputs and outputs.

Characteristics:
  • Power supply distribution to 4 doors
  • RS485 bus distribution to 4 doors
  • 4 supply outputs 12V/1.0A
  • 4 supply outputs 12V/0.2A
  • Power supply lost signalling output
  • Battery charging with 0.3A, 0.6A or 0.9A current
  • Protection against deep battery discharge
  • Supplied from 13.8VDC/5.4A PSU e.g. PS4D

Roger PSD4D Supply and bus distributor module

Roger PSD4D Supply and bus distributor module


Technical Specification:
  • Power supply: 13.8VDC; +/- 100mV
  • Supply current: up to 6,0A (depend on the expected electrical loads)
  • AUX+/AUX-: auxiliary power output 13.8VDC/0.2A
  • VOUT+/VOUT-: auxiliary power output 13.8VDC/0.2A
  • VDRx+/VDRx-: main power output 13.8VDC/1.0A
  • TML+/TML-: terminal power output 13.8VDC/0.2A
  • Power supply lost output: 15VDC/15mA
  • Battery charging current: 0.3A; 0.6A; 0.9A
  • Battery cut-off voltage: app. 10.0V
  • Distributor to controller cable length: max. 1200m
  • Distributor to terminal cable length: max. 150m
  • Environmental class: I
  • Workingtemperature: +5°C to +40°C
  • Dimensions: 96x80mm
  • Weight: 85g
Download
Datasheet 0.29 MB
CE Declaration 0.13 MB
Operating Manual 1.02 MB
