Satel SDA-250 Autonomous smoke detector

Satel SDA-250 Autonomous smoke detector

The device enables immediate detection of fire symptoms. Detection of smoke triggers sound and light alarms.
SDA–250 operates autonomously, in accordance with the guidelines of the EN 14604 standard.

The detector is equipped with a photoelectric visible smoke sensor placed in a special measuring chamber, the unique design of which ensures high sensitivity. The precise Hexamesh stainless steel filter protects against parts of dirt and small insects from getting inside.
The alarm is signaled acoustically and optically. In addition, the detector monitors the condition of the optical chamber - if it is dusty, the LED diode signals the need for maintenance.

SDA–250 is characterized by low energy consumption. The model is powered by a CR123A 3 V battery, the status of which is monitored - a voltage drop below a specified level is signalled optically and acoustically.

FEATURES:

• loud acoustic signaling thanks to the use of a piezoelectric transducer
• optical signaling using an LED indicator
• resistance to dirt thanks to the precise stainless steel Hexamesh filter
• accelerated smoke detection thanks to the unique Swirl chamber
• self-diagnostic functions: control of battery status and level of dirt in the optical chamber (the detector automatically compensates for gradual changes in the optical chamber caused by dust deposition)
• button for testing and resetting the alarm
• signaling in test mode using an LED diode
• expected battery life (CR123A 3V) is 10 years
• the device does not require connection to the power supply
• it can be use in rooms with humidity of 93±3%
• operates at temperatures from 0°C to +55°C
• the device meets the requirements of the EN 14604 standard for autonomous detectors (certificate issued by the Scientific and Research Centre for Fire Protection)
• the detector has an EU declaration of conformity – RED 2014/53/EU (CE)
