Relay module Pulsar AWZ624

9,58 EUR including 22.00% VAT
On stock. Ships in one business day
Delivery time: 3 - 5 days
Product code: #13467
Manufacturer: Pulsar
  • The number of relays: 2
  • The number of contacts: 1
  • Coil voltage: 20-28V DC
  • Relays: 2x REL-C/NO/NC, 2A@30VDC/50VAC
Delivery and tax:
Italy VAT: 22.00% change
Shipping cost from:
12,35 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Relay module Pulsar AWZ 622 Relay module Pulsar AWZ 520 Relay module Pulsar AWZ 529 Relay module Pulsar AWZ612 Relay module Pulsar AWZ528

Relay module AWZ624 MP-2/24V

Relay module Pulsar AWZ624

Relay module Pulsar AWZ624

The MP-2/24V (AWZ624) relay module is to be used in low-voltage installations. It is intended for
controlling and status indication in e.g. alarm or access control systems. It may be used to control devices of high power consumption via OC outputs of alarm systems. Moreover, it ensures galvanic isolation of signals, power sources relating to the outputs of the module..
Relay module Pulsar AWZ624

Relay module Pulsar AWZ624



SPECIFICATIONS:
  • Voltage of the relay’s coil: 20-28V DC(-/+5%),
  • Current of the relay’s coil: 18mA 24VDC
  • Number of relays: 2
  • Voltage of the relay’s contacts: 30VDC/50VAC max
  • Current of the relay’s contacts: 2A max.
  • Contacts of relay: C/NC/NO (leads Φ2.05 mm: AWG 24-12)
  • ON/OFF time: 15ms/8ms (-/+5%)
  • Operating conditions: 2nd environmental class, -10°C÷ 40°C
  • Enclosure: open-frame design, IP00
  • Dimensions: W=70, L=43, H=22  [mm,+/-2]
  • Net/gross weight: 60g
  • Installation: installation tape or installation bolt x2
Relay module Pulsar AWZ624

Relay module Pulsar AWZ624


Download
Datasheet 0.14 MB
Declaration CE 0.32 MB
User Manual 0.14 MB
