Pulsar AWZG2-12V2A-B AWZG2 13,8V/2A/7Ah buffer power supply unit Grade 2

113,96 EUR including 22.00% VAT
Product code: #22576
Manufacturer: Pulsar
  • Battery charging current: 0.2A/0.5A
  • Battery: 1 x 7AhDimensions of battery space : 190 x 100 x 75 [+/-2 mm]
  • Current consumption by PSU systems: 11mA max.
  • Dimensions: 205 x 237 x 82 [+/-2 mm]distance from surface: 8 mm
  • Protections: SCP, OLP, OVP, UVP, tamper – opening of enclosure
Delivery and tax:
Italy VAT: 22.00% change
Shipping cost from:
12,35 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Pulsar AWZG2-12V5A-C AWZG2 13,8V/5A/17Ah buffer power supply unit Grade 2 Pulsar AWZ639 MPOC technical outputs relay module Pulsar AWZG2-12V5A-D AWZG2 13,8V/5A/40Ah buffer power supply unit Grade 2 Pulsar AWZG2-12V3A-C AWZG2 13,8V/3A/17Ah buffer power supply unit Grade 2

Pulsar AWZG2-12V2A-B AWZG2 13,8V/2A/7Ah buffer power supply unit Grade 2


Technical parameters:

  • Power supply output: 2 A / 13.8 V DC (total output current with charging) - for general purpose application 0.58 A / 13.8 V DC - GRADE 1÷2
  • Compliant with standards: Construction compliant with EN50131, GRADE 1÷2Access control norm EN60839-11
  • Battery charging current: 0.2A/0.5A
  • Battery: 1 x 7AhDimensions of battery space : 190 x 100 x 75 [+/-2 mm]
  • Current consumption by PSU systems: 11mA max.
  • Dimensions: 205 x 237 x 82 [+/-2 mm]distance from surface: 8 mm
  • Protections: SCP, OLP, OVP, UVP, tamper – opening of enclosure
  • Technical outputs OC type: EPS – AC power failureAPS – battery failure
  • Closing: bolted
  • Installation: surface-mounted
  • Indication: LED optical indication
  • Material: steel DC01, 0.7mm, RAL9003 (white), metallic
  • IP protection class: IP 20
  • Warranty: 5 years
Download
Data sheet 0.4 MB
Instruction 1.13 MB
