Proxima NMx FLOR 1-channel universal receiver

Universal single-channel NMx receiver FLOR

The following remotes can be programmed to the controller:

• FLOR system remote controls - (leading system) service rolling code, ensures high security against copying
• remote controls from other manufacturers with HCS chips, operating in the 433MHz band

APPLICATION
The biggest advantage of the NMx receiver is the ability to load different remote controls producers.
This function can be used when we want to use different remote controls systems for controlling the gate drive or barrier in the company. Employees who in their homes they already have automation from different manufacturers with the same remote control they open the gate or barrier in the company. This reduces the cost of additional purchases pilots and employees do not need to carry more pilots with them.

Single-channel universal controller, powered by direct or alternating current with a voltage of 12V or 24V. Up to 31 can be programmed into the receiver remotes in the FLOR + system, you can additionally program other remotes producers.

Keep in mind that the convenient operation of one automation remote control is different producers at the cost of reduced security. Using the remotes non-system ones, we run the risk of transmission interception.

BASIC PARAMETERS

• Power: AC/DC 12-24V
• Current draw: 10 mA relay off
• Exits:
• • NO relay load 24V-0.5A
  • NC relay load 24V-0.5A
• P short (works like a button on the case)
• Number of remotes: 31
• Number of channels: 1 (relay channel)
• Channel modes:

• • Monostable (1,3,5,25 seconds)
  • Bistable
  • TDJN (As Long As You Press)
• Dimensions: 37x41x17mm
• Weight: 23g


ADDITIONAL FUNCTIONS

• superheterodyne receiver - range up to 200m
• assembly grommet in the housing allows the installation of a clamp
• acoustic confirmation of receiving the remote signal (programmable option)- different for system remote different for non-system remote
• can be selected (programmed option) whether in registered key fobs whether only the registered button or all buttons are active registered pilot
• acoustic signaling for one minute of low remote control battery
• a registered system remote can:
• • read acoustically the number of programmed remotes,
  • register a new keyfob (programmed option),
  • delete key fob - the key fob to be deleted must be available (option programmed),
  • delete all remotes except the remote that carried out deletion, so it is possible to re-register remotes remotely without access to the controller (programmed option).
