NiceHome MAESTRO200M actuator without control unit

NiceHome MAESTRO200M actuator without control unit

A actuator for swing gates with a folding arm with a maximum leaf length of 2.2m with a maximum weight of 150kg or with a maximum weight of 250kg, with a maximum length of 1.6m.
the drive is powered by 24 V DC and is equipped with an unlocking mechanism with a key that allows the gate to be moved manually in the event of a power failure.

FEATURES:

• Fast: Open or close the gate in 8 seconds (opening to an angle of 90 degrees, soft start and release disabled)
• Easy installation: Trouble-free installation of the entire set. Connection of accessories using 2-wire cables (Bus technology)
• Safe: Possibility of equipping the set with an emergency battery, thanks to which you can open or close the gate in the event of a power failure
• For every gate: Thanks to the use of a folding arm, it can be installed on most posts. Fits any architecture
• User-friendly: Full compatibility with the SoleKit solar power system and the possibility of using wireless accessories

TECHNICAL DATA:

• Power supply: 230V
• Motor power: 150W
• Maximum opening angle: 110°
• Opening time of the swing gate to an opening angle of 90°: 8s
• Maximum starting torque: 150 Nm
• Nominal torque: 50 Nm
• Speed without load: 3 RPM
• Speed at nominal torque: 2.7 RPM
• Maximum cycle frequency: 20 cycles/hour
• Maximum continuous operation time: 10 minutes
• Control function with intercom
• Wind gate function
• Works with solar panel
• Manual unlocking in the event of a power cut
• Battery operation in the event of a power cut
• Accessory power supply: Electric cable (bus system)
• Ambient operating temperature: -20°C ... +50°C
• Protection class: IP54
• Dimensions: 237 x 155 x 290 mm
• Weight: 6.2kg
