HLG-320H-24B Mean Well 24V/320W/13.34A LED power supply

159,05 EUR including 22.00% VAT
Product code: #22617
Manufacturer: Pulsar
  • Output parameters: DC 24V 13.34A max 320W
  • Possibility of remote control of output current
  • Built-in Active PFC function
  • 3 in 1 dimming
  • Lifetime > 62000h

Delivery and tax:
Italy VAT: 22.00% change
Shipping cost from:
12,35 EUR

Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
HLG-185H-C500B Mean Well 185W/500mA LED power supply Pulsar HLG-185H-48 HLG 48V/187.2W/3.9A LED power supply HLG-120H-12B Mean Well 12V/120W/10A LED power supply Pulsar HLG-100H-36 HLG 36V/95.4W/2.65A power supply Pulsar HLG-100H-24A HLG 24V/100W/4A LED power supply Pulsar HLG-240H-C1400B HLG 240W/1400mA LED power supply Pulsar HLG-150H-24B HLG 24V/151.2W/6.3A LED power supply HLG-120H-12A Mean Well 12V/120W/10A LED power supply HLG-80H-12B Mean Well 12V/60W/5A LED power supply HLG-240H-54A Mean Well 54V/240W/4.45A LED power supply

MEAN WELL HLG-320H-24B LED power supply 24V/320W/13.34A


The HLG-320H-24B constant-current power supply for lighting systems has a power of 320W and the output voltage of 24V. It is closed in a metal housing IP67 and is cooled with open air circulation .
HLG-320H-24B has the ability to remotely adjust the output current - input DIN 3W1 (1 ÷ 10VDC / PWM / resistance). It also has an active PFC function built in and 3in1 dimming function.

PARAMETERS AND FEATURES:
  • output voltage: DC 24V
  • output voltage adjustment range: 12-40VDC
  • output current: 13.34A
  • output current adjustment range: 6.67 - 13.34A
  • power: 320.16W
  • wide input voltage range: 90-305VAC, 127-431VDC
  • protection:
    • short circuit protection
    • overcurrent
    • overvoltage
    • thermal
  • free air cooling
  • built-in Active PFC
  • class II isolation
  • power supply life: >62000h
  • efficiency: 94%
  • cable
    • AC power: 0.3m
    • DC power: 0.3m
  • working temperature: -40 ° C ÷ 90 ° C
  • dimensions: 252x90x43.8mm
  • weight: 1.88kg

Download
Datasheet 0.86 MB
CE Declaration 0.32 MB
