Satel PERFECTA 32 WRL LTE Control panel with GSM/LTE

Satel PERFECTA 32 WRL LTE Control panel with GSM/LTE

The control panel is intended for alarm installations in small buildings, apartments, small houses, commercial premises summer houses. Allows for construction wired, wireless or hybrid system connecting both systems.

One of the most important advantages of the PERFECTA 32-WRL LTE control panel is its capability build an inexpensive alarm system in facilities already finished without the need for cables, thanks to the built-in radio module operates at 433 MHz.

The alarm system based on the PERFECTA control panel is distinguished by its simple configuration, intuitive operation and convenient control. The control panel provides protection in accordance with Grade 2 EN 50131 requirements
System configuration can be done by:

• computer with PERFECTA Soft program installed
• remotely - thanks to data transmission from the cellular network and using the keypad

CONTROL PANEL PARAMETERS AND FUNCTIONS

• 8 programmable hardwired inputs on board

• • expansion to 32 using INT-E expanders
  • configuration selection NO, NC, EOL, 2EOL/NO, 2EOL/NC
  • support for roller shutter and vibration detectors
• 4 programmable hardwired outputs on board
• • extension to 12 using the INT-O expander
  • two power outputs
• additional 4 wireless outputs for wireless operation MSP-300 sirens

• 2 partitions witch 3 arming modes in each partition
• 8 programmable timers with exception handling

• integrated modules:
• • cell phone with 2 nano-SIM slots
  • cell phone with 2 nano-SIM slots
  • audio alarm verification module
  • 433 MHz radio module
• local system operation by means of PRF-LCD wired or wireless PRF-LCD-WRL keypads (max 4 pcs)
• MPT-350 remote control support
• wireless communication:
• • two-way with PRF-LCD-WRL keypads and MSP-300 R sirens
  • one-way with MICRA series detectors and MPT-350 keyfobs
• support up to 15 users + 1 service
• memory of 3584 events
• built-in switch-mode power supply
• • over-current protection
  • battery deep discharge protection
  • battery charging current control

The control panel works with a wide range of SATEL devices:

• all wired motion detectors

• wired optical-acoustic signaling devices
• wireless motion detectors, opening windows and doors cooperating with MICRA alarm module

• MSP-300 wireless siren

• expansion module INT-E, INT-O


The PERFECTA control panel is a very functional device. Quick configuration can be carried out from the manipulator. Convenient access to all functions from any place is possible through the PERFECTA Soft program. Program using a modern intuitive interface leads step by step through subsequent stages of creating the installation.

KEYPADS AND REMOTE CONTROL FOR PERFECTA CONTROL PANEL
