S64H 6-port switch with power supply in hermetic enclosure

Pulsar S64H 6-port switch with power supply for 4 IP cameras in hermetic enclosure

S64H is a 6-ports PoE switch designed to supply IP cameras operating in IEEE 802.3af/at standard. Automatic detection of any devices powered in the PoE/PoE+ standard is enabled at the 1 – 4 ports of the switch. The UpLink ports is used for connection of another network device via RJ45 connector. The LEDs at the front panel indicate the operation status.

The PoE technology ensures a network connection and reduces installation costs by eliminating the need to supply a separate power cable for each device. This method allows supplying other network devices, such as IP phone, wireless access point or router.

Features:

• Long Range mode (up to 250m)
• Supports auto-learning and auto-aging of MAC addresses (1K size)
• LED indication
• Pole mounting option (requires the OZB2 adapter - optional accessory)
• Built-in switch mode power supply PSCL520115
• IP56 hermetic enclosure

FEATURES:

• 6 port 10/100Mbit
• 4 x PoE (10/100Mb/s)
• 2 x UPLINK (10/100Mb/s)
• power: 100-240 V
• power supply: 52 V DC / 1.15 A / 60 W max.
• PoE IEEE 802.3af/at, DC 52V, 30W per port
• total power consumption: max 30W
• dimensions: 421 x 535 x 193mm
• glands:
• • 6 x Φ=4÷8mm
  • 1 x Φ=10÷14mm
• weight: 1.3kg
• operating temperature: -25°C...+50°C
