Roger RKD32-SE-8 Key depositor with 10'' touchscreen control panel

Roger RKD32-SE-8 Electronic Key Depositor with 10” Touchscreen Control Panel

The RKD32-SE-8 key depositor is an electro-mechanical system for distributing and monitoring key circulation within a facility. Each monitored key is permanently attached to a key fob containing a unique radio frequency (RFID) proximity identifier. The key is attached to the fob by the system user and does not require specialized equipment or additional seals.

RKD32-SE-8 key depositors can operate in standalone or networked mode. When operating in networked mode, configuration and monitoring of key circulation is performed using the RACS 5 access control system software (Roger), and depositor users can use the same identifiers as in the access control system. In the standalone version, the depositor can be managed from a touchscreen control panel or Remotely, from a web browser.

FEATURES:

• Standalone operation or within the RACS 5 access control system
• Local management via the touch panel
• Remote management via the web browser
• Remote management via the RACS 5 access control system software (VISO application)
• Graphical touch panel with a 10” screen
• ISO/IEC 14443A MIFARE® Ultralight, Classic, Plus, and DESFire EV1, EV2, EV3 card reader
• Supports encrypted MIFARE® card sectors
• Ability to connect an external reader with a Wiegand interface
• Ability to connect an external reader with a Roger RS485 interface
• 8 keys per safe RKD32-SE main safe deposit box
• Option to connect 3 RKD32EXT or RKD24CT-EXT expansion safe deposit boxes to the RKD32-SE main safe deposit box
• Permanent key-fob connection without the use of seals
• Option to use seals connecting the key to the key fob
• Mechanical key lock in the pocket
• Contactless key identification and presence control via MIFARE® proximity tag
• Multi-level key access authorization system with time schedules
• Limit the number of keys collected by the user
• Division of keys into internal and external zones external
• key collection option by commission
• dual identification mode: card + PIN
• key loan timeout indication
• quick key return option without the need to identify the person returning the key
• operating mode with a fixed or variable key location
• alarm event reporting via email
• automatic indication of the key's location in the deposit box
• free access to all keys at selected time intervals or on request (Office Mode)
• key reservation
• user activity reporting
• key circulation reporting
• generating and sending reports
• emergency unlocking of all keys via an external signal (e.g., from the fire alarm control panel)
• emergency unlocking of keys from Emergency panel level
• Detection of safe deposit box door opening
• Detection of safe deposit box housing opening (anti-sabotage)
• Metal housing in RAL7016 color
• Dimensions RKD32-SE: 600 x 969 x 182 mm (H x W x D)
• Weight RKD32-SE: 39 kg
• Built-in 230 VAC buffer power supply
• Space for an 18 Ah battery
• Post-warranty service
• No warranty inspections required
