Pulsar EPP-150-48 Open frame power supply 48V/150W/3.125A

66,95 EUR including 23.00% VAT
Product code: #27351
Manufacturer: Pulsar
  • Output voltage: DC 48V
  • Rated current: 3.125A
  • No load power consumption: <0.5W
  • Built-in active PFC function
  • Built-in 12V/0.3A auxiliary output
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Pulsar EPP-300-48 EPP 48V/300W/6.25A open frame power supply Pulsar EPP-150-12 EPP 12V/150W/8.4A open frame power supply Pulsar EPP-100-27 EPP 27V/100W/3.71A open frame power supply Pulsar EPP-300-27 EPP 27V/300W/11.12A open frame power supply Pulsar EPP-200-24 Open frame power supply 24V/201.6W/8.4A Pulsar EPP-150-27 Open frame power supply 27V/150W/5.56A Pulsar EPP-100-48 Open frame power supply 48V/100W/2.1A Pulsar EPP-100-15 Open frame power supply 15V/100W/6.67A

Pulsar EPP-150-48 Open frame power supply 48V/150W/3.125A


The EPP-150-48 open frame power supply has a wide power supply range of 90 - 264 V AC, 127 - 370 V DC, built-in active PFC and built-in output auxiliary 12V/0.3A.
It is equipped with security features:
  • short-circuit proof SCP
  • overload OLP
  • surge
  • temperature exceeded
TECHNICAL DATA:
  • output voltage: 90 ~ 264VAC
  • output voltage adjustment range: 47.04 ~ 50.4V
  • output voltage: 48V
  • current efficiency: 3.125A
  • power: 150W
  • efficiency: 92%
  • ripple voltage: 300 mV p-p max.
  • LED optical signaling
  • operating temperature: -30°C...+70°C
  • dimensions: 101.6x50.8x29mm
  • weight: 200g
  • no housing, built-in module
Download
Datasheet 0.61 MB
CE Declaration 0.61 MB
