Pulsar DSOS24V Firefighter’s microphone power supply for Voice Alarm Systems 24V

578,21 EUR including 23.00% VAT
Product code: #13470
Manufacturer: Pulsar
  • Power supply: 176 - 264 V AC
  • Power supply output: 0.2 A / 24 V DC
  • Battery charging current: 0.4A
  • Dimensions of battery space: 1 x 7Ah
  • Dimensions: 550 x 380 x 200 [+/-2 mm]
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Pulsar DSOS24V Firefighter’s microphone power supply for Voice Alarm Systems 24V


Technical parameters:

  • Destination: Power supply for call station of DSO, e.g. PVA-15CST and two PVA-20CSE extensions by BOSCH
  • Power supply: 176 - 264 V AC
  • Power supply output: 0.2 A / 24 V DC
  • Compliant with standards: Certification with Fire protection standard EN54-4Certification with Smoke extraction and ventilation standard EN12101-10Certificate of constancy of performance CNBOP-PIB No 1438-CPR-0504Certificate of approval CNBOP-PIB No. 4421/2021
  • Battery charging current: 0.4A
  • Dimensions of battery space: 1 x 7Ah
  • Dimensions: 550 x 380 x 200 [+/-2 mm]
  • Protections: SCP, OLP, UVP
  • Technical outputs relay type: EPS – AC power failurePSU – power supply failureAPS – battery failure ALARM – collective failure
  • Closing: lock for fire ax
  • Installation: surface-mounted
  • Indication: LED optical indication, BUZZER
  • Material: steel DC01, 1mm, RAL3001 (red), metallic
  • IP protection class: IP 30
  • Warranty: 3 years
  • Notes: - power supply unit is fitted with an RJ45 connector for call station (microphone) connection - power supply unit is fitted with screw terminals („IN") for connecting „CDSO" transmission cable from DSO control panel
Download
Data sheet 2.22 MB
Instruction 0.7 MB
