Heatit Z-TRM3 Thermostat for electric heating

245,82 EUR including 22.00% VAT
Product code: #33945
Manufacturer: Fibaro
  • Built-in Z-Wave chip
  • For mounting in a flush-mounted box
  • SmartStart function
  • Temperature range: 5°C to 40°C
  • Floor sensor included
Delivery and tax:
Italy VAT: 22.00% change
Shipping cost from:
12,35 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Heatit Z-WATER Water heating controller

Heatit Z-TRM3 Thermostat for electric heating, white


A wired thermostat designed to operate electric heating floor. It has a built-in Z-Wave chip that allows you to connect it to smart home system.
The device will withstand a maximum load of 16A / 3600W at 230V. At higher levels loads, the thermostat must control the contactor. The thermostat allows connection to two wired external sensors.

The thermostat has a SmartStart function that allows the user configuration by scanning QR codes. After booting, all devices will be automatically integrated with the headquarters, which significantly reduces the time installation.

Thermostat features:
  • Floor sensor included
  • Weekly program
  • Temperature limiter
  • Power measurement
  • Status LED
  • Single pole switch
  • Lock mode
  • Calibration
  • 5 associations
  • Temperature read at the gate
  • SmartStart
The thermostat is equipped with a single-pole switch and fits into the System frame 55. Has a floor sensor included. It also allows you to determine temperature limiter at which the thermostat will stop heating completely. The device operates in the temperature range 5°C to 40°C

TECHNICAL DATA:
  • Protocol: Z-Wave – 868.4 MHz (EU)
  • Chip: Z-Wave 500
  • Rated voltage: 230 V 50/60 Hz
  • Maximum load: 3600 W (resistive load), self-limiting heating cable 750 W
  • Maximum current: 16A
  • Power consumption (own): < 2.0W
  • Ambient temperature: 0° C to 40° C (during operation)
  • Temperature range: 5° C to 40° C
  • Hysteresis: 0.3° C to 3.0° C (default 0.5° C)
  • Compatible with NTC sensors with values: 10, 12, 15, 22, 33 and 47 kΩ @ 25 ° C
  • IP 21
