Elmes ST100H-3K 3-channel universal 230V radio controller

36,11 EUR including 23.00% VAT
Product code: #27233
Manufacturer: Elmes
  • 3x 230V AC outputs
  • 3-channel radio controller
  • Works with 1, 2 or 3 remote control buttons
  • Independent or sequential control of 2 or 3 devices
  • Channel operation on/off or with hold time
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Elmes ST100H-3K 3-channel universal radio controller 230V

Controller is powered from the 230VAC network and is intended for remote switching 3 devices.
The device uses the KEELOQ variable code system, which means that each the transmission to the receiver is coded and different than the previous one. It ensures this the highest level of system security.
The ST100H-3K controller works with all Elmes remote controls for band 433.92 MHz. With the help of 4-, 8- and 32-channel remote controls, independent operation is possible control 3 devices, when working with 1 remote control button (e.g. with a remote control 1-channel) sequential operation is possible. Control any three devices can also be connected to wired switches. The way they are operation is identical to that of the remote control buttons.

Has the following functions:
  • works with 1, 2 or 3 remote control buttons
  • independent or sequential control of 2 or 3 devices
  • work in on/off mode
  • operation in on/off mode plus automatic shutdown after programmed time (from 0.5 s to 4 hours)
SPECIFICATIONS:
  • 433.92MHZ receiver (superheterodyne)
  • remote memory: 12 (option 112)
  • controller power supply: 230VAC, 2VA
  • outputs 1 and 2: relay, max. 16A/250VAC
  • output 3: relay, max. 5A/250VAC
  • automatic shutdown time: from 0.5 s to 4 hours, common to all devices
  • dimensions: 87x87x39mm
