Aco INSPIRO PMR 2+ Master Inspiro Outside unit with code lock, module for the disabled, electronic list and RFID reader

902,66 EUR including 23.00% VAT
Product code: #22877
Manufacturer: ACO
  • Max. amount of phones: 1020 apartments
  • Code block and electronic list
  • Camera: heated, min. 600 lines, lens 2,8mm
  • DM - Module for disabled INS-DM
  • Integrated with the bottom description place RFID reader Unique 125 kHz
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Aco TR-Aco Proximity key ring - black Aco CDN-U Signal module with door opening function Aco SW4S-DIN 4 zone switch for INSPIRO + panels

INSPIRO PMR 2+ Outside unit with code lock, module for the disabled, electronic list and RFID reader



A version of the INSPIRO panel created for people with disabilities. A 2mm thick brushed stainless steel panel is resistant for all weather conditions, damage or vandalism.
The device is compatible with all digital devices from the groups: CDN, Inspiro and Familio PV and programming is done using a USB cable, through CPU or computer (without external power supply).

To make it easier for disabled people, the panel has backlights Braille keys, optical signaling and sound and built-in T-loop. No additional necessity answering calls we can remotely or automatically open the door at CDN-U module, we can connect an additional acoustic device in the premises or light signals that someone is calling.

Modules:
  • High resolution color camera
    • 2.8mm wide-angle lens
    • high resolution (600 lines)
    • horizontal angle adjustment +/- 20 °
  • DM - Module for disabled INS-DM:
    • T induction loop
    • speech synthesizer (sound signaling)
    • three LEDs (optical signaling)
  • 230E - electronic, alphabetic list of apartments
  • combination lock
  • Unique 125 kHz (ACC) proximity key fob reader
Features:
  • resistant to weather conditions and acts of vandalism
  • option of setting a 6-digit apartment number
  • 4 different code tables
  • available codes: 1020 apartment (4-digit), 5 administrator (4 or 6-digit), 1 technician (8-digit)
  • programmable entry on the main display (max. 30 characters)
  • adjustable max. talk time (40-120 seconds)
  • support for multiple expansion modules increasing the system functionality
  • support for multi-input Master/Slave/Multimaster systems
  • optional SW4S-DIN module required for 1020 apartments
  • opening of an e-lock or additional relay output without a call (CDN-I/O)
  • external device control (CDN-I/O module) – triple key
  • enabling or disabling access to external device control separately for each apartment
  • option of connecting multiple receivers under the same number using active receivers
  • many options of individual configuration for each apartment
  • intuitive and comfortable operation and configuration
  • group change of calling range
  • group change of call numbers
  • option of setting up to 8 numbers, including the option of calling without talking
  • auto-opening function for each apartment
  • corridor opening function
  • gatekeeper function
  • option of entering any max. 6 character text on the display during gatekeeper redirection
  • adjustable number of openings during talk (1-3)
  • operation of e-locks and maglocks of various types
  • 8 priority additional numbers with individual settings of calling parameters
  • call forwarding for additional numbers
  • built-in induction loop (marked with an international symbol) for people using a hearing aid – the voice from the intercom loudspeaker is sent directly to the hearing aid
  • built-in visual indicators: the red diode signals calling the apartment, the yellow diode signals that the call has been taken, the green diode indicates door opening
  • built-in sound indication – a synthesizer that plays the following messages: "selection pending, please wait" (when calling the apartment), "the door is open, please enter" or "the number is not responding, try again later"
  • messages are available in the following languages: Polish, English and French, according to the set language of the displayed messages in the intercom
  • programming with a computer without external power supply
  • programming with the control panel and computer using a USB cable
  • free software available in the "download" tab
  • compatible with all digital devices from the groups: CDN, Inspiro and Familio P/PV

TECHNICAL SPECIFICATIONS:
  • mounting method: flush-mounted
  • dimensions:
    • panel: 111x412mm
    • flush-mounted box: 92x393x31.52mm
  • installation type: digitalm - cat. 5e or 6
  • line lenght: max 1000m
  • power supply: 15V DC
  • stand-by power consumption: 4W
  • first outputs to be connected:
    • traditional electric door strike (max 1A)
    • reversible door strike (max 0.5A)
    • CDN-PK relay module (max 5A)
  • second relay outputs for connection:
    • home automation (max. 2A,30VDC)
  • input: 1x NO
