Somfy 1051029 LT 50 Vectran 50/12 VVF 2,5 m drive

389,17 EUR including 23.00% VAT
Product code: #30988
Manufacturer: Somfy
  • 50NM/12r.pm.
  • Power supply: 230V AC
  • Cable length: 2.5m
  • Max. load: 96kg
  • Degree of protection: IP 44 / Cable: VVF
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

SOMFY 1051029 LT 50 Vectran 50/12 VVF 2,5 m drive


Strong, proven and durable drives for roller shutters and sunshades. Achieved torques of 10 – 50 Nm enable motorization of roller shutters and other devices of the shading technology. Quick setting of end positions using push-in adjustment switches.

Technical data:

  • Length of the complete drive 605 mm
  • Diameter 45 mm, adapted to an octagonal shaft fi 60 mm
  • Power supply 230V/50Hz
  • Nominal torque 40 Nm
  • Nominal speed 12 revolutions / min.
  • Continuous operation time 4 min.
  • Power consumption 240 W
  • Protection class IP 44
  • Max. load capacity approx. 96 kg (with a roller shutter height of up to 250 cm)
  • Mechanical adjustment of end positions
