Satel APS-30 S 12V 3A backup power supply with housing

116,14 EUR including 23.00% VAT
Product code: #24490
Manufacturer: Satel
  • 3A power supply load capacity
  • Stabilization of the output voltage
  • Place for 7Ah battery
  • Technical outputs
  • LED optical signaling
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Satel APS-30 S 12V 3A backup power supply with housing


The APS-30 S switch mode power supply is designed for devices that require 12 VDC nominal voltage.
The set includes: power supply, transformer, enclosure and additional accessories: tamper switches, spacers, connecting cables for transformer, wall plugs (anchors) and screws.

Features
  • Nominal output voltage (according to IEC 38): 12 VDC
  • Output voltage stabilization
  • Battery status control and low battery disconnect system
  • Ability to work without a battery connected
  • Output current:
    • operation with battery: 2,5 A / 2 A
    • operation without battery: 3 A
  • Battery charging current: 0,5 A / 1 A (selectable)
  • Pins enabling configuration of the power supply settings
  • 3 LEDs to indicate:
    • AC mains power supply status
    • battery status
    • battery charging
  • 2 OC outputs to indicate the following troubles:
    • AC mains power loss
    • low battery
  • Acoustic signaling of troubles
  • Electronic short-circuit protection of AC mains power supply circuit
  • Short-circuit protection fuse for battery charging circuit (T 3,15 A)
  • Electronic short-circuit and overload protection of the power output
  • Tamper protection against enclosure opening and removal from mounting surface
The transformer should be permanently connected to the 230 VAC mains supply. Before you make the cabling, familiarize yourself with the electrical installation of the facility. Make sure that the circuit you choose for powering will be always alive. The circuit should be protected with a proper safety device.

Specifications
  • Power supply type (according to EN 50131): A
  • Transformer power supply voltage: 230 VAC
  • Electronics board power supply voltage (from transformer): 17-24 VAC
  • Nominal output voltage (according to IEC 38): 12 VDC
  • Output current
    • operation with battery connected: 3 A
    • operation without battery connected: 2.5 A / 2 A
  • Battery charging current (selectable): 0.5 А / 1 А
  • Recommended battery: 12 V / 7 Ah
  • Current consumption of power supply circuits: 80 mA
  • Battery failure voltage threshold : 11 V ±10%
  • Battery cut-off voltage: 9.5 V ±10%
  • OC type outputs (AWS, AWB): 50 mA / 12 VDC
  • Environmental class: I
  • Operating temperature range: +5...+40 °C
  • Electronics board dimensions: 140 x 99 mm
  • Enclosure dimensions: 266 x 286 x 100 mm
  • Weight (without battery): 2.45 kg
Download
User Manual 0.66 MB
