Roger Technology NAVI NV/200/SX Left-hand drive with 36V brushless motor

Roger Technology NAVI NV/200/SX Left-hand drive with 36V brushless motor for accordion gates

SCOPE OF APPLICATION

• Single-leaf doors:
• • Max. leaf length: 2m
  • Max. leaf weight: 300kg
• Double-leaf folding doors:
• • Max. leaf length: 1.5m
  • Max. leaf weight: 200kg

The NV/200/SX NAVI actuator is a solution for the automation of entrance and garage gates with accordion wings and single ones. Thanks to the use of a 36 V AC brushless motor and IPU technology, it ensures smooth and precise movement of the gate even with large dimensions. A mechanical limiter for opening and closing with a sliding arm and a three-stage planetary gear ensure reliability and durability of operation.

The drive is designed for intensive work without time limits, the opening speed to 90° is only 10 seconds. Thanks to the non-self-locking drive and the digital control unit in IPU technology, precise control over the gate movement is ensured.

Thanks to the use of a digital encoder and encoder management technology, precision of movement and safety of use are ensured.

FEATURES:

• Smooth gate movement even with large dimensions
• Opening time up to 900 10s
• Intensive use - continuous operation without restrictions
• Mechanical limiter for opening and closing with a sliding arm
• Three-stage planetary gear
• Non-self-locking drive
• Digital control unit without relays in IPU technology
• Digital encoder management
• High work culture
• Very low energy consumption

TECHNICAL DATA:

• Mains power supply: 230 V AC - 50 Hz
• Motor power supply: 36 V
• Rated power: 240W
• Use frequency: Intensive
• Force: 240 N
• Gear motor type: Non-self-locking
• Speed: 0.75- 2.8 Rpm
• Opening time to 90°: 10 s
• Limit switches: Opening limiter
• Control unit: F70/IPU36
• Encoder: Built-in digital + magnetic digital SENSORED, 48 pulses per rotation
• Number of cycles per day: no cycle limit
• Operating temperature: -20°C / +55°C
• Protection class: IP44
• Weight: 18.2 kg
