Pulsar WDR-480-48 WDR 48V/480W/10A DIN rail power supply units

273,22 EUR including 19.00% VAT
Product code: #22805
Manufacturer: Pulsar
  • Power supply: 180 - 550 V AC - single-phase/two-phase, 254 - 780 V DC
  • Power supply output: 10 A / 48 V DCvoltage adjustment range: 48 - 55 V DC
  • Efficiency: 91%
  • Dimensions: 85.5 x 125.2 x 128.5 [+/-2 mm]
  • Protections: SCP, OLP, OVP, OHP

Delivery and tax:
Germany VAT: 19.00% change
Shipping cost from:
10,84 EUR

Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Pulsar WDR-60-5 WDR 5V/50W/10A DIN rail power supply units Pulsar WDR-240-48 WDR 48V/240W/5A DIN rail power supply units Pulsar WDR-240-24 WDR 24V/240W/10A DIN rail power supply units Pulsar WDR-120-48 WDR 48V/120W/2.5A DIN rail power supply units Pulsar WDR-120-24 WDR 24V/120W/5A DIN rail power supply units WDR-480-24 Mean Well 24V/20A/480W DIN rail power supply WDR-120-12 Mean Well 12V/10A/120W DIN rail power supply Pulsar WDR-60-12 WDR 12V/60W/5A DIN rail power supply units

Pulsar WDR-480-48 WDR 48V/480W/10A DIN rail power supply units


Technical parameters:

  • Power supply: 180 - 550 V AC - single-phase/two-phase, 254 - 780 V DC
  • Power supply output: 10 A / 48 V DCvoltage adjustment range: 48 - 55 V DC
  • Efficiency: 91%
  • Dimensions: 85.5 x 125.2 x 128.5 [+/-2 mm]
  • Protections: SCP, OLP, OVP, OHP
  • Technical outputs relay type: DC OK - output voltage control
  • Indication: LED optical indication
  • Warranty: 3 years

  • Download
    Data sheet 0.13 MB
