Pulsar RPB-1600-24 Charger for batteries

701,21 EUR including 23.00% VAT
Product code: #22691
Manufacturer: Pulsar
  • Output voltage: DC 24V
  • Battery charging current: 55A
  • Technical outputs OC type
  • For lead-acid and lithium-ion batteries

Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
52,62 EUR

Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Pulsar RPB-1600-24 Charger for batterie


The PB-1600-24 is an AC / DC charger with single output and 3 step process charging the battery. It is dedicated to lead-acid batteries and lithium-ion.
The device has an output voltage adjustment in the range of 23.5 ÷ 30VDC and possibility of increasing the total power of the system to 4800W (2 + 1).

FEATURES:
  • PFC function active
  • 3-stage loading with the ability to change characteristics
  • built-in IIC interface, PMBus
  • short circuit, over voltage, temperature protection
  • protection against low battery voltage / disconnection battery
  • cooling with built-in fan
  • thermal voltage compensation
  • adjustable output current and voltage
  • up to 3 units can be connected in parallel
  • remote turn on / off
  • wide operating temperature range
TECHNICAL DATA:
  • power supply: 90 ÷ 264VAC, 127 ÷ 370VDC
  • power output: 55A / 28.8VDC
  • output voltage adjustment range: 23.5 ÷ 30VDC
  • battery charging current: 55A
  • efficiency: 92.5%
  • security features: SCP, OVP, UVP, OHP
  • technical outputs of OC type:
    • DC OK - Check the output voltage
    • T-ALARM - charger temperature control
  • working temperature: -30 ℃ ~ + 70 ℃
  • dimensions: 300 x 41 x 85
  • weight: 1.8kg

Download
Datasheet 0.33 MB
CE Declaration 0.45 MB
