PSG 61.019.16 Adjustable hinge with plate M16 100x100x4 mm

5,81 EUR including 23.00% VAT
Product code: #41148
  • The maximum load of a pair of hinges on a 2 m long door leaf is 65 kg
  • Ear width: 43 mm
  • Total length: 88 mm
  • Screw length: 40 mm | Thread: M20
  • Sign size: 100x100 mm
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

PSG 61.019.16 Adjustable hinge with M16 plate 100x100x4 mm


Steel adjustable hinge with M16 screw. It has a plate with dimensions of 100x100 mm with four holes for screwing. Designed for the assembly of swing gates or wickets. Galvanized product - intended for external use, provides high corrosion resistance.

Using this hinge will help with simple and quick adjustment after the assembly is completed, using an adjusting nut. At any time, you can adjust the hinge, e.g. in the case of hanging the structure or when extreme temperatures occur.
The metal will become tense under the influence of, e.g. a sudden drop in temperature in winter. In such situations, you can loosen the adjustable hinge or tighten it as needed.

Permissible load of a pair of hinges on a 2m long wing: 65 kg.

FEATURES:

  • Galvanized - provides high protection against corrosion for many years
  • Simple, quick assembly
  • Possibility of adjustment after assembly
  • High quality of workmanship affects resistance to mechanical damage and load

Technical data:

  • Material: Steel
  • Anti-corrosion protection: Galvanized (black ear)
  • Thread: M16
  • Ear width: 43 mm
  • Total length: 88 mm
  • Screw length: 40 mm
  • Signature size: 100x100 mm
  • Sheet metal thickness sign: 4 mm
