Proxima SB control panel for controlling a two-phase induction drive

69,74 EUR including 23.00% VAT
Product code: #25332
Manufacturer: Proxima
  • Built-in limit switches
  • A controller with an output for photocells and a signal lamp
  • 8 work scenarios
  • Memory of 25 remote controls
  • Self-closing
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,53 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Proxima SB control unit for controlling a two-phase induction drive


After making the purchase, contact us and tell us which system the control panel should cooperate with.



A controller for a rolling or sliding gate with built-in limit switches surface mounted. It is designed to control an induction drive two-phase.
The controller has an output for photocells and an output for the lamp signaling, which can work in one of four modes:
  • lighting + 60s
  • lighting - when the gate is open
  • warning - 60s when gate is open
  • warning and lighting - when the gate is open
Furthermore, there is a STOP (NC) control input, an OPEN input, an input CLOSE, OPEN and CLOSE inputs also independently in TDJN mode (Tak Long Jak You press - DEADMAN).

FEATURES:
  • automatic closing after 1 minute of opening
  • automatic closing after 1 minute of opening, shortened after the vehicle has passed (5s or 15s)
  • programmable opening / closing time 4-240s
  • programmed time of partial opening with the remote control - wicket function 4-240s
  • memory of 25 pilots
  • built-in radio receiver (variable Keeloq remote code - 433.92MHz)
  • confirming receipt of pilot tone with buzzer
  • sealed housing with space for cables
The controller can be operated with the remote control and as many as the button of each remote control can act in accordance with one of eight scenarios:
  • Step by Step - open - stop - close - stop
  • closing, and when it is moving - stop
  • to open, and when it is moving stop
  • opening
  • stop
  • shutdown
  • partial open
  • closing TDJN - Deadman
Please note, however, that under one remote control, button scenarios cannot be repeated.
The control panel has outputs for local (manual) control.

The SB control panel is compatible with the following systems:
  • ALLMATIC
  • APRIMATIC
  • BENINCA
  • BFT
  • CAME SPACE
  • DEA
  • DOORHAN
  • ELDRIM
  • ELMES
  • ERREKA
  • FAAC FIX
  • FAAC RC
  • FLOR
  • GORKE
  • KEY
  • MOOVO/MHOUSE
  • NORMSTAHL
  • NOVOFERM
  • PROXIMA
  • SMILO
  • WIŚNIOWSKI
  • WIŚNIOWSKI MIDO
TECHNICAL DATA:
  • power supply: 230AC / 50Hz
  • motor: 1kW 2 phase inductive
  • number of remotes: 25 rolling code
  • frequency: 433.92MHz
  • lamp: 100W
  • dimensions: 165 x 123 x 67mm
Download
CE Declaration 0.07 MB
