Proxima Remote control BOX APRIMATIC with dynamically changing code,
Bi:KLIK
BOX remote control is a modern transmitter for sending radio commands, using a
momentary switch, one or two push buttons. Designed is to control radio
receivers, gate and roller shutter controllers and other devices compatible
with the APRIMATIC system.
The BOX Bi:KLIK socket outlet is actually two remotes in one housing:
- the first remote control is available as usual, "normally",
after ONEKLIK
- the second remote control is available after pressing the TIP button
twice quickly
The correct operation of the remote control is indicated by the green LED
of the remote control, and the battery for replacement is indicated by the red
LED, while the three-digit LED indicator can be checked - very good - good -
sufficient and for replacement.
The programming button is the third button of the remote control, also having
Bi:KLIK functions.
The remote control is based on the KeeLoq system with a dynamically changing
code, which is difficult to copy by third parties.
To register the remote control in the controller, it is required to use the
so-called hidden button. Remote Bi: KLIK sends SEED only when remote control
battery is at least sufficient - the LED on the remote control is green. The
ONE / DOUBLE keyfob starts sending the hidden code the (SEED) button after a
30-second long one or two clicks. The sending of the SEED is signaled by the
LED flashing red (433MHz) or green (868MHz). Flashing is simultaneous two-digit
information about the number of the coding system. In BFT and APRIMATIC
systems, the remote starts sending SEEDa also by pressing two buttons
simultaneously. The sending of the SEED is signaled by the LED shining constant
light.
SPECIFICATIONS:
- frequency: 433.92MHz
- number of buttons: 2
- number of channels: 4
- power supply: 1x CR2032 3V battery
- dimensions: 52x25x9mm
