Proxima NW2 HORMANN BISECUR 2-channel

Proxima NW2 radio receiver compatible with radio HÖRMANN BISECUR - 250 pilots

Miniature superheterodyne radio receiver 868.3 MHz equipped with two relay outputs NO. It can work with 250 pilots. The controller is ideal for control systems, gate automation, blinds and security systems of buildings. Will be used in situations where one remote you want to control the automation from different manufacturers.

PRODUCT FEATURES

• miniature size, simple installation
• works in a rolling code manner with Hörmann BiSecur remote controls on frequency 868MHz
• works fixed-code with blue buttons of gray remote controls Hörmann
• long operating range up to 200m (superheterodyne receiver with high sensitivity)
• you can remove a single keyfob button, a keyfob with a removable button must be available (if it is a BiSecur clone button, it will be automatically added again the next time you use it)
• two modes of operation:
• • bistable with reset
  • monostable (uptime 1-999s)
• integrated buzzer, acoustic confirmation response pilots, output activation


Programming mode a particular channel, operating time monostable mode and operations pilots performed using only one button. Navigating the menus and programming facilitates the acoustic driver.

TECHNICAL PARAMETERS way radio: HÖRMANN BISECUR number of channels: 2 the number of pilots: 250 power supply: 12-24 V DC / AC current consumption: 30mA output load: 1A 2x 24V/500mA operating frequency: 868.3MHz dimensions: 37x41x15mm hole diameter 4/8mm weight 23g

Proxima NW2 HÖRMANN BISECUR 2-channel 868MHz 250 pilots
