Proxima NW1 1-channel controller/receiver MARANTEC 433 MHz

52,69 EUR including 20.00% VAT
Product code: #30478
Manufacturer: Proxima
  • Number of supported remotes: 909
  • Number of channels: 1
  • Power supply: 12-24V AC/DC
  • Operating modes: monostable (1-999s), bistable, TDJN
  • Radio path: MARANTEC 433 MHz
Delivery and tax:
France metropolitan VAT: 20.00% change
Shipping cost from:
12,76 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Proxima NW1 1-channel MARANTEC 433 MHz controller/receiver


NW1 is a universal receiver designed to work with gate control units and other automation systems. It works with MARANTEC 433 MHz radio remote controls. NW1 has a memory for 909 remote controls. The receiver is small and can be mounted using a cable tie. Programming the receiver is done with one button, and navigating through the device's menu is confirmed by the built-in buzzer and the receiver's LED diode..

FEATURES:

  • Full NO / COM / NC relay
  • Ability to connect an external antenna (8,5 cm dedicated wire included)
  • Superheterodyne receiver (range up to 200 meters)
  • Acoustic confirmation of receiving the remote control signal (can be turned off)
  • Acoustic signaling for one minute of a low battery in the remote control
  • Ability to delete a single remote control
  • Ability to register a single remote control button and several simultaneously pressed buttons of a given remote control

TECHNICAL DATA:

  • Power supply: 12-24V AC/DC
  • Current consumption: 10mA
  • Remote control memory: 909
  • Outputs: 1 channel NO/NC (24V, 1A)
  • Channel operating modes: monostable (1-999 s), bistable, TDJN (As Long As You Press)
  • Dimensions: 37 x 41 x 15 mm
  • Weight: 23 g
