Proxima NM_P Proxima 433.92 MHz Controller/Receiver

Proxima NM_P Proxima 433.92 MHz Controller/Receiver

NM_P is a receiver designed to work with gate control units and other automation systems. It works in a rolling code with remote controls with the Proxima 433.92 MHz radio path. NM_P has a memory for 42 remote controls. The receiver is small in size and can be mounted using a cable tie. The receiver is programmed with one button, and navigating through the device's menu is confirmed by the built-in buzzer and the receiver's LED.

FEATURES:

• Full NO / COM / NC relay – three relay operating modes
• Ability to connect an external antenna (17 cm dedicated wire included)
• Superheterodyne receiver (range up to 200 meters)
• Acoustic confirmation of receiving the remote control signal (can be turned off)
• Acoustic signaling for one minute of low battery in the remote control
• With the help of a registered remote control from the Proxima system, it is possible to: acoustically read the number of programmed remote controls, delete a single remote control, delete all remote controls except the remote control that performed the deletion
• Ability to choose whether only the registered button or all buttons of the registered remote control should be active in the registered remote controls

TECHNICAL DATA:

• Power supply: 12-24V AC/DC
• Current consumption: 10mA
• Remote control memory: 42
• Outputs: 1 channel NO/NC (24V, 1A)
• Channel operating modes: monostable (1-3-5-25 s), bistable, TDJN (As Long As You Press)
• Dimensions: 37 x 41 x 15 mm
• Weight: 23 g
