Nice ON3EBD 3-channel remote two-way
The ON3EBD transmitter is designed to control automations (gates, garage
doors, road barriers and similar). ON3EBD is compatible with receivers that
adopt both the one-way “O-Code” and the two-way “BD” radio encoding systems.
Nice ON3EBD 3-channel remote two-way
The remote control provides radio control with dynamically variable code,
with the frequency 433.92 MHz, which gives a high level of security of use,
and makes the code impossible to copy.
The ON3EBD transmitter, configured in twoway mode, can be memorised on
maximum 10 two-way receivers (OXIBD). Configured in one-way mode, it can be
memorised on any desired number of one-way receivers.
The two-way communication between the ON3EBD transmitter and the OXIBD
receiver has the following functions:
- sending of the receiver’s confirmation of the command received:
-
- command received
- command not received
- sending of the automation’s status
- indication of the automation’s anomaly status
ON3EBD is configured by default with the twoway ''BD'' radio
encoding. If the system’s automation uses the one-way
''O-Cod'' encoding system, for each command key to be
associated with the automation the “encoding switch” procedure must be
carried out. This procedure allows for modifying the type of encoding system
(''O-Code'' or ''BD'') associated with a
single command key.
TECHNICAL PARAMETERS
- number of channels: 3
- frequency: 433.92 MHz
- radio code: rolling code, 192-bit O-code and BD
- the power supply: 3V lithium battery CR2032
- battery life: about two years assuming 10 transmissions a day
- degree of protection: IP40
- operating temperature: -5°C...+55°C
- dimensions: 45x56x11mm
- weight: 18g
The ON3EBD remote control can be mounted on the dashboard of the car thanks
to the dedicated bracket. The range of transmitters and the ability to
receive receivers depends on other devices (alarms, radio headphones, etc.)
operating in a given zone on the same frequency.
