Nice KingGates ROLLS1200 Operator for garage doors up to 240cm high

Product code: #43862
Manufacturer: KingGates
  • maximum thrust: 1200N
  • surface of the gate: up to 23m²
  • built-in control unit STAR GDO 100
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,54 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.
DRIVE INTENDED USE:
Automation of garage doors up to 240cm high:
  • Max. sectional door area: 23m²
  • Max. swing door area: 14m²
TECHNICAL PARAMETERS:
  • Pulse force: 1200N
  • Work intensity: 60 cycles per day
  • Power supply: 230V
  • Motor power supply: 24V
  • Power consumption: 300W
  • IP40
  • Operating temperature: -20°C ÷ +55°C
  • Dimensions: 414x264x110mm
KINGgates ROLLS 1200 Set for garage doors

KINGgates ROLLS 1200 Set for garage doors


PRODUCT DESCRIPTION:
Easy-to-use and highly functional garage door operator. A pulling force of 1200 N is sufficient for operating a tilt-and-turn door up to 14 m² and a sectional door up to 23 m².
The rotating cover gives the user easy access to the control unit. Metric screws ensure the operator's rail mounting.
The drive is transmitted via a durable, reinforced toothed belt, making the drive quiet and maintenance-free.
The innovative manual release system allows the gate to be released on the drive carriage or via an external unlocking system. Thanks to the option of installing BAT 12K emergency batteries, the drive can operate effectively even when there is no mains power. The gate can then be manually opened and closed without having to re-release it, and after closing the gate manually, it can be opened automatically.

The ROLLS 1200 has a built-in STAR GDO100 control unit, which is easy and intuitive to use – it has a plastic cover equipped with three programming buttons.

CONTROL UNIT FEATURES AND FUNCTIONS
  • Option to control additional lighting
  • Built-in radio receiver, compatible with KING GATES remotes
  • Programmable using 3 buttons
  • Built-in encoder
  • Built-in indicator light
  • Built-in antenna
    • Operation in "open - pause - close" mode
    • Operation in "step-by-step" mode
    • Automatic closing function
    • Soft start function
    • Auto-test function
Download
User manual 0.93 MB
