Mco Home OS12 Occupancy sensor

Mco Home OS12 Occupancy sensor

MCO Home OS12 is a Z-Wave occupancy sensor based on 24GHz millimeter wave Doppler technology, it can accurately detect and distinguish motion, minor motion and even breathing signals to interact with lights, shutters, fans, air conditioning and various electrical appliances, as well as security alarm, person monitoring etc. Suitable for home, hotel, office and other places, not affected by temperature, humidity, noise, airflow, dust, light and other factors. Sensor can be added into any Z-Wave network, and is compatible with any other Z-Wave certified devices.

Detecting range

• 3db horizontal beam angle up to 80°, vertical beam angle up to 85°, with high accuracy and wide detection range.
• Maximum range of respiratory presence: 2-3m in diameter
• Maximum range of minor presence: 3-4m in diameter
• Maximum range of motion presence: 5-8m in diameter
• The switch time of detecting absence or presence: within 0.5sec

Specification

• Power Supply: AC90-250V (optional DC12V)
• Comes with 5A dry contact output
• Ultra-low RF power output, harmless to human health
• Maximum Transmitting Power: +13dbm
• Visual LED indicator for pairing network or detecting the movement, minor motion, breathing
• Operating Temperature: -10℃-50℃
• Operating humidity: 20%-85%（non-condensing）
• Z-Wave 800 series, support S2 encryption
• Z-Wave Frequency: Operating frequency range, defined by the regulatory bodies (for Z-wave in Europe: 868.4 MHz, or other regions 908.4/916.0 MHz , 921.4 MHz)
• Housing: V0 flame-retardant PC material
• Installation: Top-mounted or wall-mounted
