Fibaro Walli Roller Shutter FGWREU-111

FIBARO Walli Roller Shutter intelligent controller of roller shutters, shutters and gates garage FGWREU-111

FIBARO Walli Roller Shutter is a smart wall switch designed to control motors of roller blinds, awnings, venetian blinds and other single phase, AC powered devices via Z-Wave network. It measures active power and energy consumed by the controlled load.

TECHNICAL PARAMETERS:

• Power supply: 110-230V~50/60 Hz
• Rated load current:
• • 4A for motors with compensated power factor (inductive loads)
  • 13A for resistive loads
• Overcurrent circuit breaker recommended
• • fuse 10A type B (EU)
  • fuse 13A type B (Sweden)
• Recommended wire cross-section: 1.5-4.0mm2
• For mounting in boxes: Ø = 60mm, gł. ≥ 40mm
• Radio protocol: Z-Wave
• Transmit power:: EIRP maks. 6dBm
• Radio frequency: 868.4 lub 869.85 MHz EU 869.0 MHz RU
• Range:
• • up to 50m outdoors
  • up to 40m indoors
• Working temperature: 0-35 °C
• Dimensions: 86x86x51
• Color: white

PACKAGE CONTAINS:

• Roller Shutter Unit FG-WREU111-AS-8001
• Single decorative frame FG-Wx-PP-0001
• Switch button with fiber FG-WDSEU221-AS-8100
• Mounting frame FIBARO / Gira55 FG-Wx-AS-4001

Product code: FGWDEU-111
