Fadini BAYT 980 9895SXL Manual automatic barrier left-hand side
A barrier ideal for locations where it is not possible to connect to the power
supply.
The barrier body can be protected with cataphoresis and covered with a
polyester powder coating in two colours: graphite RAL 7016, while the top cover
and door are textured grey 9006 SW3061, or made of brushed AISI 304 stainless
steel.
It is possible to transform the manual barrier into an automatic one even later
by mounting the COS 982 motor-pump-piston assembly to it.
SOLID
Reinforced structure in powder-coated steel with high resistance
to weather conditions or in AISI 304 stainless steel. Anodised aluminium arm
with oval cross-section, various dimensions, aluminium connector; high
resistance to wind.
UNIVERSAL
A wide range of accessories: arm with aluminum curtain, arm
with integrated LED lighting ensuring good visibility at night (flash signal
effect optional), joint for articulated arm enabling installation in roofed
rooms, collar protecting the arm in the event of a collision with a vehicle.
QUICK INSTALLATION
Control unit located in the upper part of the
housing, in a separate, designated space. "Master/slave" function for
operating opposing barriers.
PRACTICAL
Version with manual arm operation (max. length 6.40 m without
aluminum curtain). Ideal for locations where connection to the power supply is
not possible.
Technical data:
- Power supply (Vac – Hz): 230 - 50
- Power consumption (W): 510
- Current consumption (A): 2.4
- Power efficiency (kW – HP): 0.37 - 0.5
- Operating temperature (°C): -20 ÷ +80
- Working pressure (atm): 20
- Max. pressure (atm): 40
- IP protection class: 65
- Oil type: 708L
- Tank volume (l): 2.5
- Weight without beam (kg): 75
- Use frequency: very intensive
