Fadini 482L APROLI 480 230V Drive for swing gates up to 7 m²

648,56 EUR including 22.00% VAT
Product code: #36945
Manufacturer: Fadini
  • Power supply: 230V AC
  • Opening/closing time: ~ 18 s [205°]
  • Door area: 7 m²
  • Frequency of use: intensive
  • Protection class: IP67
Delivery and tax:
Italy VAT: 22.00% change
Shipping cost from:
12,35 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Items bought with this product:
Fadini 483L Fastening kit for mounting one APROLI 480 drive Fadini 244L External emergency release kit for APROLI 480 drive Fadini 708L FADINI HF.PLI oil for hydraulic installations canister 2L Fadini 513L Pair (left and right) of curved telescopic arms for APROLI 480v drive Fadini 512L Fastening kit for mounting one APROLI 480 drive Fadini 511L Pair of curved telescopic arms in galvanized steel for APROLI 480 drive Fadini 510L Cover with additional light in case of installation of one APROLI 480 drive Fadini 486L Galvanized steel mounting bracket for APROLI 480 drive Fadini 484L Fixing kit for mounting two APROLI 480 drives on the same gate

Fadini 482L APROLI 480 230V Operator for swing gates up to 7 m²


APROLI 480 230V hydraulic operator for swing gates up to 7 m² for residential use.

ATTENTION! Does not include fastening elements.

SOLID AND QUIET

230 V AC hydraulic operator for swing gates, both fully and partially retractable indoors. Bypass valves ensure safety against crushing.

EASY TO USE

Easy to mount and install, even on existing installations.

FUNCTIONAL

Slim design with built-in lighting.

BIDIRECTIONAL HYDRAULIC LOCK

The gate remains locked in both the closed and open position (when the motor is not running). To manually open or close the leaf, the actuator must first be unlocked.

HYDRAULICS POWER TECHNOLOGY

A cylinder using a motion transmission system using hydraulic oil under pressure.

Technical data:

  • Power supply: 230V - 50Hz
  • Power consumption: 330W
  • Current consumption: 1.8A
  • Power efficiency: 0.24kW - 0.33HP
  • Torque: 220-300 Nm
  • Operating temperature: -20°C ÷ +80°C *
  • Open/close time: ~ 18 s [205°]
  • Protection class: IP67
  • Oil type: 708L
  • Weight: 11 kg
  • Door surface: 7 m²
  • Use frequency: intensive
* -40°C with specific optional accessories
Download
User manual 4.45 MB
