Came HG600 Operator for garage doors up to 10m2

Product code: #43867
Manufacturer: CAME
  • maximum thrust: 600N
  • surface of the gate: up to 10m²
  • max. gate height 3m
Delivery and tax:
Poland VAT: 23.00% change
Shipping cost from:
2,54 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

Came HG600 Operator for garage doors up to 10m2


An easy-to-use yet highly functional garage door operator. Its 600 N pulling force is sufficient to operate a tilt-and-turn or sectional door up to 10 m².
Maximum door height: 3 m

The operator is equipped with a lamp illuminating the garage interior and a control unit. It has a self-locking gear, a die-cast aluminum body, and an ABS housing.

The control unit features the following functions, among others:
  • Step-by-step control (open-stop-close)
  • Automatic closing
  • Adjustable overload sensitivity
  • Adjustable automatic closing time
Technical specifications:
  • Main power supply for the entire drive: 230 V, 50 (60) Hz
  • Motor power supply: 24 V
  • Motor power: 100 W
  • Opening speed: 5.77 m/min.
  • Utility lighting: 25 W 24 V
  • Shaft torque: 7 Nm
  • Maximum thrust force: 600 N
  • Programming: panel with digital display
  • Protection class: IP22
  • Maximum gate height: 3m (rail 3.9m)
  • Operating temperature range: -20°C ~ +50°C
  • Weight: 5.8kg
