BFT 2611715 Hydraulic drive for industrial folding doors FORB E

1370,33 EUR including 20.00% VAT
Product code: #38673
Manufacturer: BFT
  • Max. panel length: 2m (two panels)
  • Max. weight of one panel: 360kg
  • Power supply: 230V
  • For very intensive work
  • Degree of protection: IP 20
Delivery and tax:
France metropolitan VAT: 20.00% change
Shipping cost from:
12,76 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

BFT 2611715 Hydraulic drive for industrial folding doors FORB E


Hydraulic drive for very intensive use for industrial folding doors, maximum two panels per leaf.
Designed for the toughest conditions of use, it combines the strength and typical reliability of hydraulic drives.
BY-PASS valves allow precise torque adjustment during opening and closing.

FEATURES:

  • Hydraulic release guarantees quiet and smooth movement even for the largest gates
  • The adjusting screw also allows the release intensity to be adjusted to any requirements
  • Bypass valves allow precise torque adjustment during opening and closing in a separate and independent manner
  • Durable, anodized aluminum construction

Technical data:

  • Connectivity - no
  • Control unit - RIGEL 6
  • Rated voltage - 230 V
  • Power consumption - 250 W
  • Maximum area - 2.4 m2
  • Gate area - 2.4 m2
  • Slowdown - YES
  • Lock none
  • Unlocking - Lever or steel cable
  • Impact response - Crush protection provided by 2 bypass valves
  • Use frequency - very intensive
  • Protection class IP20
  • Operating environment (max.) - -15 ÷ 60 °C
Download
User's Guide 7.25 MB
