A14AB – One control unit for all, for controlling all AVO 24Vdc PRO series actuators.

The control unit is also designed for the NIGHT LIGHT SYSTEM to control LED lighting during the night.

Programming the A14AB control unit is only possible using the KUBE PRO wireless module.

All kits containing the A14AB control unit allow you to connect up to 20 additional LEDs to automatically illuminate your driveway.

FEATURES:

• Possibility of combining modules depending on the installation (1 or 2 actuators)
• Same programming procedure for all systems
• Amperometric sensitivity with reverse movement
• Standard or programmable slowdown during opening and closing
• Programmable automatic closing time (pedestrian function)
• 24V/25W warning light output
• Remote-controlled auxiliary lighting output (24V/15W)
• Electric lock output (12VAC/15VA)
• 2 analog photocell inputs
• STOP input operating as NC
• Safety input compatible with an 8.2 ohm resistive edge kΩ
• 4 control inputs: step-by-step, open, close, gate
• Input for connecting a dedicated ARX4K radio receiver

CONTROL UNIT FUNCTIONS:

• Human presence: YES
• Semi-automatic operation: YES
• Automatic operation: YES
• Apartment complex: YES
• Pre-flashing: YES
• Phototest during opening: YES
• Soft start: YES
• Soft stop: YES
• Additional lighting: YES
• Gate status monitoring: YES
• Slow-down function: YES
• Electric strike release: YES
• Electrical limit switch cut-off: YES
• Pause during opening: YES
• STEP-BY-STEP function: YES
• Separate opening and closing: YES
• Amperometrics: YES
• Adjustable delay during opening: YES
• Brake: NO
• Cycle counter: YES
• Display: NO
• Encoder: YES
• Close after photo: YES
• Wicket function: YES
• Electric strike: YES
• Energy saving: YES
• Behavior after power failure: YES
• Sensitive edge connection: YES
• Amperometric sensitivity: YES
• Solar power supply: YES
