ATTE ACSDC-15-120 Step-down converter 24VAC/12VDC

17,62 EUR including 20.00% VAT
On stock. Ships in one business day
Delivery time: 3 - 5 days
Product code: #36424
Manufacturer: Atte
  • Input voltage: 20-28V AC
  • Output voltage: 12V DC
  • Power: 15W
  • Dimensions 20 x 63 x 20 mm
Delivery and tax:
France metropolitan VAT: 20.00% change
Shipping cost from:
12,76 EUR
Payment methods:
We can deliver packages to most countries around the world, shipping cost is calculated in the cart. Price of the product varies due to the VAT of the destination country.

ATTE ACSDC-15-120 Step-down converter 24VAC/12VDCM

The ACSDC-15-120 is a non-isolated step-down converter. The device is powered by voltage of 20 - 28 VAC and provides a stabilized output voltage of 12V. The ASDC/ACSDC group converters are high-efficiency voltage-lowering modules. Device provides stable power supply for elements of alarm systems, cameras, WLAN devices, etc. It is used to power remote electronic devices via a standard one steam twisted pair.

TECHNICAL DATA

  • Supply voltage: 20 ... 28 VAC
  • Output voltage: 12 VDC
  • Output power: 15 W @24VAC
  • Efficiency: 92% @VIN=24VAC, POUT=15W
  • Converter no-load current: 10mA @24VAC
  • Power indication: PWR LED (red) - power supply present
  • Operating temperature range: -25°C ... +50°C
  • Dimensions: 20 x 63 x 20 mm
  • Weight: 0.015 kg
