AJAX TurretCam (5Mp/2.8mm) 5Mpx IP Camera (Black)
The AJAX TurretCam 5Mpx (2.8mm/4mm) is a wired IP camera with intelligent
infrared (IR) illumination with a range of up to 50m, allowing for operation in
low light and darkness.
The camera is equipped with a 2.8mm/4mm lens, allowing for recording at a
resolution of 2880x1620 (5Mpx) at 25 fps. A special feature of the TurretCam is
its AI-assisted motion and object recognition (classification of objects as
people, pets, and vehicles).
The camera also has a built-in microphone and a microSD card slot for up to
256GB. Network connection is via 10/100Mbps Ethernet using the appropriate
connector, and power can be supplied either from a 12V DC power supply or PoE
802.at.
The camera housing is made of metal and has an IP65 rating and an IK08
mechanical resistance.
Note! TurretCam can operate without an Ajax NVR, saving data to an SD
card if one is installed. Otherwise, an Ajax NVR is required.
FEATURES:
- MicroSD card slot: up to 256GB
- Metal housing: IP65 rating
- Microphone: G722 codec
- Infrared illuminator: up to 50m
- Accelerometer: reports removal and shock
Motion detection
Optimize your video archive by configuring the pixel
motion detection feature.
Define specific zones to ensure that recordings are only triggered when motion
occurs in a specific area.
This saves space and improves archive navigation.
AI Analysis
Thanks to AI analysis capabilities, cameras can recognize a
variety of objects, enabling selective recording.
This ensures only relevant events are recorded, such as a person entering a
room or a car entering a parking lot.
Processing is performed by the camera, reducing infrastructure load and saving
memory compared to traditional motion sensors, which operate by detecting the
movement of pixels on a screen.
Privacy Zones
Increase privacy by creating privacy zones. This feature
allows you to hide part of the image.
For example, if a safe is in view, you can monitor activity around it without
revealing its contents by setting a zone.
This option ensures that personal and sensitive information remains private,
especially in high-security environments.
Comprehensive monitoring with video wall
Ajax cameras feature a clear
interface that integrates with alarm systems to provide comprehensive
protection.
They offer a video wall that allows you to view large areas or different
locations in real time. The video wall updates in real time without overloading
the system.
You can easily access data and quickly switch to live viewing. The video wall
is accessible via the Ajax mobile and desktop apps.
JetSparrow Technology
Ajax cameras provide unparalleled speed and
convenience in video transmission. JetSparrow's innovative Ajax video
transmission technology powers fast and smooth operation.
The substream allows for fast and smooth scrolling through recordings, and
JetSparrow instantly provides the user with the entire recording. The substream
can be easily configured in the app.
JetSparrow guarantees high loading speeds, ensuring smooth and seamless app
navigation.
Set up scenarios in which Ajax sensors activate specific cameras and initiate
video recording. Configure video settings for instant visual confirmation of
alarms in high resolution.
- Peer-to-peer transmission
- TLS encryption
- High stability
Technical Specifications:
- Focal Length: 2.8mm
- Viewing Angle 2.8mm: 100° ~ 110°
- Aperture Type: Fixed
- Illumination Type: IR
- Range: 50 m
- Intelligent Illuminator: Yes
- Number of LEDs: 1x
- LED Type: OSRAM SFH4713A
- Wavelength: 850 nm
- Maximum Resolution: 5.0 Mpx, 2880×1620 pixels
- Processing Speed: 25 fps
- Compression: H.265 / H.264
- Video Protocol: JetSparrow
- Bitrate Control: CBR / VBR
- Recording Archiving: NVR / microSD Card
- Day/Night Mode: Automatic
- Image Enhancement Features: HDR
- WDR: True WDR
- Privacy Zones: 4x
- Image Features: Rotation, Saturation, Brightness, Contrast,
Sharpness
- Built-in Microphone: Yes
- Compression: G.711ulaw / G.711alaw / G.726 / G.722
- Live View: Up to 5 Channels Simultaneously
- Users: Supports up to 200 users
- Remote Support: Ajax, Ajax PRO
- Object detection: Yes, recognition of detected object type
(human/animal/vehicle)
- Alarm triggering methods: Motion detection, recognition using artificial
intelligence (AI), sensor alarm, automation scenarios
- Network: 1x RJ-45 10/100 Base-T/Base-TX
- Memory: 1x microSD/microSDHC/microSDXC card slot, up to 256 GB
- Reset: 1x button
- Standard compliance: CE / RoHS / NDAA
- Ingress protection: IP65
- Mechanical resistance: IK08
- Power supply: 12V DC (±25%): PoE (802.3at)
- Power consumption: DC: max. 15W (1A, 12V DC) / PoE: max. 7.5W
(802.3at)
- Humidity: ≤90% (non-condensing)
- Operating temperature: -25°C ~ +40°C
- Material: Metal
- Includes: Camera, installation accessories, quick start guide
- Available colors: White / Black
- Weight: 496g
- Dimensions (W x L x H): 98 x 98 x 103mm
