| Camera |
Image Sensor |
1/2.8" progressive scan CMOS |
|
Min. Illumination |
Color: 0.028Lux @ (F2.0, AGC ON) |
|
Shutter Speed |
1/3 s to 1/100, 000 s |
|
Slow Shutter |
Yes |
|
Day &Night |
IR cut filter |
|
Wide Dynamic Range |
DWDR |
|
Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360° |
|
DNR |
3D DNR |
| Lens |
Lens |
2.8 mm, 4 mm |
|
Auto-Iris |
No |
|
Aperture |
F2.0 |
|
Focus |
Fixed |
|
FOV |
2.8 horizontal FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5°,4 mm,
horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5° |
|
Lens Mount |
M12 |
| Illuminator |
IR Range |
Up to 30 m |
|
Wavelength |
850 nm |
| Video |
Max. Resolution |
1920 × 1080 |
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 Sub stream:
H.265/H.264/MJPEG |
|
H.264 Type |
Main Profile/High Profile/Baseline Profile |
|
H.265 Type |
Main Profile |
|
Video Bit Rate |
32 Kbps to 8 Mbps |
| Smart Feature-Set |
Region of Interest |
1 fixed region for main stream |
| Image |
Image Enhancement |
BLC, 3D DNR |
|
Image Setting |
Saturation, brightness, contrast, sharpness, AGC, white balance
adjustable by client software or web browser |
|
Day/Night Switch |
Auto, scheduled, day, night |
|
Main Stream Max. Frame Rate |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 ×
1080, 1280 × 960, 1280 × 720) |
|
Sub-stream Max. Frame Rate |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480,
640 × 360, 320 × 240) |
| Network |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS,
UDP |
|
API |
ONVIF (PROFILE S), ISAPI |
|
Simultaneous Live View |
Up to 6 channels |
|
User/Host |
Up to 32 users,3 levels: Administrator, Operator and User |
|
Client |
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 |
|
Web Browser |
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
|
Alarm Trigger |
Motion detection, video tampering alarm, illegal login |
| Interface |
Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| General |
Firmware Version |
V5.5.83 |
|
General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask,
watermark |
|
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less
(non-condensing) |
|
Power Supply |
12 VDC ± 25%, 5.5 mm coaxial power plug,PoE (802.3af, class 3) |
|
Material |
Camera body: metal, bottom base : plastic |
|
Dimensions |
Camera: Ø 110 mm × 93.2 mm (4.3" × 3.7"),With package: 150 mm
× 150 mm × 141 mm (5.9" × 5.9" × 5.6") |
|
Weight |
Camera: approx. 360 g (0.8 lb.),With package: approx. 610 g (1.3
lb.) |
|
Power Consumption and Current |
12 VDC, 0.3 A, max: 3.5 W,PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A,
Max: 4.5 W |
|
Interface Protection |
IP67 |
